Product Summary

The IXTP05N100 is a High Voltage MOSFET. Applications include Switch-mode and resonant-mode, power supplies, Flyback inverters, DC choppers and High frequency matching.

Parametrics

IXTP05N100 absolute maximum ratings: (1)International standard packages; (2)High voltage; (3)Rugged polysilicon gate cell structure; (4)Fast switching times.

Features

IXTP05N100 features: (1)DSS: 1000V; (2)VDGR: 1000V; (3)VGS-Continuous: ±30V; (4)VGSM-Transient; ±40V; (5)ID25: 750mA; (6)IDM: 3A; (7)Mounting torque: 1.13/10 Nm/lb.in.; (8)Weight:4g.

Diagrams

IXTP05N100 AB Dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IXTP05N100
IXTP05N100

Ixys

MOSFET 0.75 Amps 1000V 15 Rds

Data Sheet

Negotiable
IXTP05N100M
IXTP05N100M

Ixys

MOSFET 0.5 Amps 1000V

Data Sheet

Negotiable
IXTP05N100P
IXTP05N100P

Ixys

MOSFET Polar Pwr MOSFET 1KV w/reduced Rds(on)

Data Sheet

Negotiable
