Product Summary
The AD53037JST is a dual 8-, 10-and 12-bit buffered voltage output DAC in a 16-lead TSSOP package that operates from a single +2.5 V to +5.5 V supply consuming 230μA at 3 V. Their on-chip output amplifiers allow the outputs toswing rail-to-rail with a slew rate of 0.7 V/μs. The AD53037JST utilizes a versatile 3-wire serial interface that operates at clock rates up to 30 MHz and is compatible with standard SPI, QSPI, MICROWIRE and DSP interface standards. Applications include Portable Battery Powered Instruments, Digital Gain and Offset Adjustment, Programmable Voltage and Current Sources and Programmable Attenuators.
Parametrics
AD53037JST absolute maximum ratings: (1)VDD to GND:–0.3 V to +7 V; (2)Digital Input Voltage to GND: –0.3 V to VDD + 0.3 V; (3)Digital Output Voltage to GND: –0.3 V to VDD + 0.3 V; (4)Reference Input Voltage to GND: –0.3 V to VDD + 0.3 V; (5)VOUTA, VOUTB to GND: –0.3 V to VDD + 0.3 V; (6)Operating Temperature Range-Industrial (B Version): –40 to +105℃; (7)Storage Temperature Range: –65℃ to +150℃; (8)Junction Temperature (TJ Max): +150℃.
Features
AD53037JST features: (1)Two Buffered 8-Bit DACs in One Package; (2)16-Lead TSSOP Package; (3)Double-Buffered Input Logic; (4)Guaranteed Monotonic By Design Over All Codes; (5)Buffered/Unbuffered Reference Input Options; (6)Output Range: 0–VREF or 0–2 VREF; (7)Power-On-Reset to Zero Volts; (8)SDO Daisy-Chaining Option; (9)Simultaneous Update of DAC Outputs via LDAC Pin; (10)Asynchronous CLR Facility.
Diagrams
 |
